Application of LLC solution in Henryuan switching power supplies and chargers


 Henryuan LLC switching power supply and charger

Henryuan 300W, 420W switching power supplies and chargers are designed with LLC control scheme. The LLC design mainly considers rectification filtering, energy conversion, circuit protection and other aspects. LLC resonant converter is the most important part of energy conversion.

Using resonance technology, there are many advantages in the power conversion process. Reduce the loss of the switch tube, improve the conversion efficiency, have lower electromagnetic interference, and have a wider input and output range.

LLC resonant converter is based on resonant oscillation, mainly composed of input capacitor, transformer, resonant capacitor, rectifier circuit and control circuit. The input capacitor smoothes the input of the power supply and provides a stable input voltage for the subsequent circuit. The coupling effect of the transformer realizes the voltage rise and fall conversion, which is mainly composed of the main coil, the secondary coil and the common mode coil. The resonant capacitor forms a resonant circuit with the main coil and the secondary coil to control the waveform and frequency of the voltage. Suitable resonant capacitors are used to meet the needs of different loads. The control circuit controls and adjusts the LLC resonant converter according to factors such as load requirements and input voltage fluctuations to meet stable power conversion.

Henryuan LLC chargers:
Li-Ion Battery Chargers: 12.6V 20A, 25A li-ion battery chargers, 29.4V 10A, 15A li-ion battery chargers, 33.6V 8A, 9A, 10A, 12.5A li-ion battery chargers, 37.8V 7A, 8A, 10A li-ion battery chargers, 42V 7A, 8A, 9A, 10A li-ion battery chargers, 46.2V 6A, 7A, 8A li-ion battery chargers, 50.4V 5A, 6A, 7A, 8A li-ion battery chargers, 54.6V 5A, 6A, 7A, 8A li-ion battery chargers, 58.8V 5A, 6A, 7A li-ion battery chargers, 63V 4A, 5A, 6A li-ion battery chargers, 67.2V 4A, 5A, 6A li-ion battery chargers, 71.4V 4A, 5A, 6A li-ion battery chargers.

LiFePO4 Battery Chargers: 14.6V 20A, 25A LiFePO4 battery chargers, 29.2V 10A, 15A LiFePO4 battery chargers, 43.8V 6A, 7A, 8A, 9A LiFePO4 battery chargers, 58.4V 5A, 6A, 7A LiFePO4 battery chargers, 73V 4A 5A LiFePO4 battery chargers.

Lead-Acid Battery Chargers: 12V 20A, 25A lead-acid battery chargers, 24V 10A, 15A lead-acid battery chargers, 36V 6A, 7A, 8A 9A lead-acid battery chargers, 48V 5A, 6A, 7A lead-acid battery chargers, 60V 4A, 5A lead-acid battery chargers.

Henryaun LLC switching Power Supplies: 12V 20A 25A power adapters, 18V 17A, 18A, 19A, 20A power adapters, 19V 15A, 20A power adapters, 20V 15A, 20A power adapters, 24V 10A, 12.5A, 15A, 17.5A power adapters, 28V 8A, 10A, 12.5A, 15A power adapters, 30V 10A, 14A power adapters, 32V 10A, 12A, 12.5A power adapters, 36V 8A, 10A power adapters, 42V 7A , 8A, 10A power adapters, 52V 5A, 6A, 7A, 8A power adapters.

Note: including but not limited to the above models. Please talk more with our engineers.
